XCMG Official 70 Ton
Rough Terrain Hydraulic Crane RT70U China New Rough Crane.
RT70U is suitable for lifting
operation in oilfields, mines, road and bridge construction, etc.
1. Energy-saving and
environment friendly
* Specialized energy-saving
hydraulic system * The torque converter with lockout function has features of
large torque at low speeds and high efficiency at high speeds. * Elevating
control system for freefall, without additional power needed.
2. High mobility and
efficiency
* Two driving types of 4×2
and 4×4 are adopted with forwards and backwards driving function. * Four
steering modes are adopted, and the min. turning radius is 19.9ft with better
job site adaptability.
3. High safety
* The crane is designed by
conforming with the safety standards of Europe, North America and China, for
optimal active protection.
4. Powerful lifting capacity
* Double-cylinder plus ropes
telescoping system, stable and reliable. * 5-section boom of 141.7ft and jib of
57.4ft with wide operation range.

| Project | Unit | Parameter |
| Length of
  Entire Vehicle | (mm) | 13135 |
| Width of
  Entire Vehicle | (mm) | 3180 |
| Height of
  Entire Vehicle | (mm) | 3750 |
| Wheel
  Base | (mm) | 4000 |
| Wheel
  Track | (mm) | 2400 |
| Gross
  Vehicle Weight When Driving | (kg) | 49065 |
| Axle Load | (kg) | (Front
  Axle)25032/(Rear Axle)24033 |
| Engine
  Type | - | QSB6.7 |
| Engine
  Rated Power | (kw/(r/min)) | 194 |
| Engine
  Max Torque | (N.m/(r/min)) | 987 |
| Max
  Travel Speed | (km/h) | 25 |
| Min
  Travel Speed | (km/h) | 2 |
