XCMG Official XGA3250D2KC Dump Truck for sale

Overall size (length×width×height)

8710×2500×3267mm

Cargobody size (length×width×height)

5800×2300×1500mm

Wheelbase

3850+1350mm

Wheel tread (Front/Rear)

2060/1860mm

Min. ground clearance

281mm

Kerb mass

15620kg

Gross vehicle weight

40000kg

Rated loading capacity

25000kg

Max. travel speed

79km/h

Min. turning diameter

17m

Max. gradeability

39%

Approach angle

25°

Departure angle

20°

Engine Brand

SINOTRUK engine WD615.47

Rated output at 2,200rpm

371HP(273kw)

Max. torque at 1400r/pm

1500N.m

Transmission Brand

FAST

Type

9JSD150A

Steering

Hydraulic steering with power assistance

Front axle

9.5T

Rear axle

16T double reduction axle

Ratio

5.73

Service brake

dual circuit compressed air brake

Parking brake

spring energy operating on rear wheels

Auxiliary brake

engine exhaust brake

Wheels rim

8.50V-20V

Tyres

12.00R20/13R22.5

Electric System

Negative grounded

Operating voltage

24V

Alternator

70A/28V

Batteries

6-QAW-165

Fuel Tank Capacity

400L
