XCMG Used Telescopic Boom Lift 22m Diesel Mobile Self Propelled Lift Tables XGS24 for Sale
XGS24 self-propelled Telescopic Mobile Elevating Work Platform highlights with outstanding performance, efficiency, dynamics and easy operation. It is leading in the industry with maximum carrying capacity of 340kg, high operation height and amplitude, suit for construction of large load and wide operation area.
Advantages and highlights: 1.Offer Test Report of Professional Institute. 2.Details Of Maintenance And Repair Items Included. 3.Price Concessions. 4.Official Factory Sourcing. 5.Reconditioning Directly From XCMG. 6.Vehicle Condition of Perfection. 7.XCMG Official Endorsement. 8.SGS Provides The Third-Party Inspection Certificate.
Item | Unit | Parameter |
Overall length of complete machine | mm | 10150 |
Overall width of complete machine | mm | 2490 |
Overall height | mm | 2800 |
Wheelbase | mm | 2500 |
Max. working height | m | 24 |
Max. platform height | m | 22 |
Max. working range | m | 18.3 |
Max. load capacity | kg | 230 (unrestricted)/340 (restricted) |
Luffing range of boom | ° | -5 ~ +75 |
Slewing angle of turntable | ° | 360 |
Max. tail swing | mm | 1550 |
Dimension of platform | mm | 2400×900 |
Slewing angle of platform | ° | 160 |
Overall weight | kg | 12500 |
Max. traveling speed | km/h | 6 |
Min. turning radius | m | 6 |
Min. ground clearance | mm | 230 |
Max. gradeability | % | 45 |
Specification of tire | - | Solid tire 36×14-20/7.5 Or Foam tire 355/55D625 |
Engine model | - | Perkins 404D-22T |
Engine rated power | kW/(r/min) | 43/(2600) |
