XCMG Stabilized Soil Mixing Plant XC500 for sale
XC500 Stabilized soil mixing plant is a product developed by XCMG on the basis of mature technology and has the advanced level in contemporary China. The equipment can produce cement stabilized soil, lime stabilized soil, industrial waste residue stabilized soil and other mixtures at all levels, fully meet the requirement of construction in expressway, classified highway, municipal administration path, airports, dams, freight yard and other projects.
XC500 Stabilized soil mixing plant has gained a number of utility models and appearance patents, which have already been applied to the equipment. The equipment possesses the batching plant which can adapt to different working medium and powder feed system for different stabilizers, adopts the advanced large-capacity twin shaft no plate forced mixing technology, intelligent control technology and so on, highlights the core features of stabilized soil mixing plant of XCMG, namely reliability, intelligence, advance and green.
| Item | Content | Unit | XC500 |
| Rated productivity(standard operating condition) | th | 500 |
| Total power | kW | 135 |
| Mixing motor power | kW | 75 |
| Minimum installation area | m | 48x14 |
Dosing precision | Aggregate | % | ≤+2 |
Filler | % | ≤士1 | |
Water | % | ≤士1 | |
Dosing system | Aggregate bin numbers | / | 4 |
Aggregate bin capacity | m' | g | |
Cement feed system | Cement bin dimension, numbers | t | 100×1 |
With small cement transfer bin | / | No | |
Mixed material silo | Capacity | m' | 8 |
Loading width | m | 4 | |
Collecting conveyor | Belt width | mm | 1000 |
Number of belt layers | / | 5 | |
Feeding conveyor | Belt width | mm | 1000 |
Number of belt layers | / | 5 | |
Shipping plan(standard) | Numbers of 16m plate trailer | l | 4 |
40 feet container(optional sheet cement bin) | l | 5 |
