Generals Model Unit HH30 HH30Z Power type Diesel Rated capacity Kg 3000 Load center mm 500 Dimensi

origin

ZHEJIANG HuaHe forklift company

Model

HH30Z

Power type

Diesel

Rated capacity

kg

3000

Load center

mm

500

Dimension

Lift height

mm

3000

Free lift height

mm

130

Fork size

N*U*L

mm

1070*125*45

Mast inclination

Front/Back

deg

6/12

Front o-verhang

mm

490

Overall dimensions

Length to face of fork

mm

2680

Overall width

mm

1225

Mast lowered height

mm

2120

Overhead guard height

mm

2120

Turning radius

mm

2460

Min. right angle aisle width

mm

2105

Performance

Travel speed

No load

km/h

9/20

Full load

mm/s

8.8/18.5

Lift speed

mm/s

480

Max. gradeability

%

20

Max. drawbar pull

Kn

14

self weight

kg

4400

Wheel&Tires

Tires

Front

28*9-15-12PR

Rear

6.50-10-10PR

Tread

Front

mm

1000

Rear

mm

970

Wheelbase

mm

1650

Min. ground (no ldad/full load)

Mast

mm

152/132

Frame

mm

158/138

Drive units

Battery

Voltage

V/Ah

12/90

Engine

Model

C490BGP

origin

CHINA

Rated output/r.p.m

kw/r.p.m

37/2650

Rated torque

N.m/r.p.m

139/1800

No. of Cylinder

4

Displacement

cc

2369

Type

Hydraulic

Shift

(Fwd/Rwd)

1/1

Operating pressure

Mpa

17.5
