3WPZ-700 Plant protection machine
Description
Recommendation
| SPRAYER SPECIFICATION | ||||
| No. | SPECIFICATION | UNIT | TECHNICAL DETAILS | |
| 1 | Type | / | Self - Propelled | |
| 2 | Model No. | / | 3WPZ-700 | |
| 3 | Overall Dimension | mm | 4860x2010x2980 | |
| 4 | Tank Capacity | L | 700 | |
| 5 | Net Weight | kg | 1620 | |
| 6 | Work Pressure | Mpa | 0.2-0.5 | |
| 7 | Nozzle Type | / | Flat Fan Spray Nozzle | |
| 8 | Spray Boom | Lifting and Drop Drive Type | / | Hydraulic |
| Fold Drive Type | Hydraulic | |||
| Boom Length | mm | 11350 | ||
| Spraying Width | mm | 12000 | ||
| 9 | Engine | Engine Type | / | Water Cooled, 4 Stroke,Four Cylinder Diesel Engine |
| Engine Power | kw/(r/min) | 36.8/2400 | ||
| 10 | Pump | Pump Type | / | Triplex Plunger Pump |
| Workig Pressure | Mpa | 1.5-4 | ||
| Flow | L/min | 36-81 | ||
| 11 | Ride Height | mm | 1050 | |
| 12 | Wheelbase | mm | 2050 | |
| 13 | Track | mm | 1520 | |
| 14 | Tire | Outer Diameter | mm | 1100 |
| Tire Width | mm | 100 | ||
| Tire Type | / | Pneumatic Tire | ||
| 15 | Brake Type | / | Friction Plate | |
| 16 | Clutch Type | / | Pressure Plate Clutch | |
| 17 | Drive System | / | Four-wheel Drive | |
| 18 | Steering System | / | Four-wheel Steering | |
| 19 | Spreader Type | / | Single-disc Spread/Double-disc Spread | |
| 20 | Spreader Lifting and Drop Type | / | Vertical Translation | |
Jiangsu Yueda Intelligent Agricultural Equipment Co., Ltd. (hereinafter referred to as "Yueda intelligent agricultural equipment") is the holding enterprise of Jiangsu Yueda Investment Co., Ltd. (Stock Code: 600805) and the core enterprise of Jiangsu Yueda Group Co., Ltd., with a registered capital of 514 million yuan, assets of 827 million yuan, more than 1000 employees and an area of more than 500 mu. The company's leading products have nearly 100 varieties, and the product power covers 16-250 horsepower. The product sales area covers more than 30 provinces, cities and autonomous regions in China, and is exported to more than 90 countries and regions such as North America, Europe, South America, Africa, Southeast Asia and the Middle East. The export delivery value has been among the best in the same industry in China for many years.
