KAT1804-F拖拉机主要参数及配置
KAT 1804-F Tractor Configurations and Specifications

上柴六缸发动机(增压、中冷),发动机12小时标定功率:132.5kW,驾驶室,暖风机,空调,法士特八档变速箱,档位:24+8,主变速同步器换挡,整体式车架,传动系统为单元式结构,国际知名品牌前桥,工程机械后桥,后双轮配置,钳盘式制动,动力输出轴转速:双转速540/1000r/min,全液压前轮转向,有三组单/双作用液压输出,耕深控制方式:位、浮动控制,悬挂机构:后置Ⅲ类。
Shangchai six cylinder engine, turbocharger, inter-cooling, 12 hours rated power: 132.5kw, fully enclosed cab, air heater, air conditioner, Fast transmission with eight shifts, 24F+8R gears, synchronizer shift, unit frame chassis, driving system with modularized structure, famous international brand front axle, construction machinery rear axle, double rear tire, caliper disc brake, PTO shaft rotation speed: 540/1000r/min, fully hydraulic front wheel steering, three groups of single/dual action hydraulic output, plough depth control method by position, floating control, and suspension mechanism of rear-mounted Category III.
    • 型号Model
    •
    • KAT1804-F
    • 发动机Engine
    • 标定功率/转速
    • Rated Power/speed
    • kW/r/min
    • 132.5(180)/2200
    • 驱动形式Drive Type
    • /
    • 4×4
    • 外形尺寸(长XX高)Dimension(Length/Width/Height)
    • mm
    • 5990/2580(double rear tyre 3710/3300
    • 轴距Wheel Base
    • mm
    • 3080
    • 前轮距Track(Front wheel)
    • mm
    • 1928-2240
    • 后轮距Track(Rear wheel)
    • mm
    • 1952-2568
    • 最小离地间隙Min. Ground Clearance
    • mm
    • 450
    • 最小使用质量Min. operation weight
    • kg
    • 8000
    • 前配重Front counter weight
    • kg
    • 500
    • 额定牵引力Rated Traction Force
    • kN
    • 40
    • 档位数No. of gears
    •
    • 24F+8R
    • 前进档Forward Gear
    • 速度Speed
    • km/h
    • 2-36
    • 倒档Reverse Gear
    • 速度Speed
    • km/h
    • 2-19
    • 轮胎Tyre Model
    • 前轮Front Tires
    • /
    • 16.9-28
    • 后轮Rear Tires
    • /
    • 20.8-38double rear tyre
    • 动力输出形式
    • Power-output shaft Type
    • /
    • 后置,独立驱动
    • Rear position, independent
    • 动力输出额定转速
    • power-output shaft Rated Speed
    • r/min
    • 540/1000
    • 最大提升力Max. Lifting force
    • kN
    • 36
